ActualLab.Fusion, the distributed state sync monster
Table of Contents
- Introduction and Background (0:00)
- Redis Baseline (0:39)
- Fusion Speed (1:08)
- What is Fusion (1:47)
- Voxt Demo (8:08)
- Compute State Component (9:17)
- Why Real-time is Hard (11:30)
- Fusion Features (15:47)
- Todo App Demo (18:48)
- Code Explanation (43:59)
- How Fusion Works (1:07:31)
- Performance and Benchmarks (1:21:29)
- Conclusion (1:49:23)
Transcript
00:00:00 so I recorded this video yesterday and after uh composing the final version I
00:00:07 realized that two hours is way too long for any kind of intro
00:00:14 so uh I decided to record a prequel to this
00:00:21 intro uh an intro for intro and uh that's uh what we are going
00:00:29 to start uh with so what you see here is uh how radius
00:00:39 performs on my machine um it's 120,000 calls per second uh and let's uh
00:00:47 think of this number as a baseline right uh you can run this Benchmark in any
00:00:52 radius container the utility is called R Benchmark so 120,000 callers calls per
00:01:02 second and that's the number you are expected to get with Fusion on the same
00:01:08 machine it's a kind of similar one
130 but million calls per second and that's if you use fusions
00:01:21 client um so it's 1,500 times speed
00:01:27 up and if you use uh Fusion just on the server side so without its client then
00:01:33 the speed up is going to be about 20x and by the way notice that this number I
00:01:39 mean almost 90,000 calls per second it's pretty similar to what you saw for Ed is
00:01:45 so in this case the underlying storage is POS gra and uh yeah obviously when
00:01:50 there is not a lot of data then they are supposed to produce nearly the same kind of results uh
00:01:57 okay uh what you see here is even crazier so um the data on right or like
00:02:06 the traffic over webset connection on the right shows that um Fusion client is
00:02:13 uh managed to resolve six calls uh using a single uh round trip to
00:02:20 the server uh so first few uh first two
00:02:25 messages are a part of handshake and basically one is outg goinging and one
00:02:31 is incoming and six calls are resolved uh so why six uh well uh we need some
00:02:39 data to resolve a user from station and show this piece right then one call is
00:02:45 for summary and three calls out for this part the first one gets the list of IDs and then like two more calls gets the
00:02:53 data and uh I think what's weird is that uh there is a clearer data depend
00:02:59 dependency right so for example you need to get the IDS first and only after that you can get the items by these IDs or
00:03:07 like to get this whole piece of data you probably need to authenticate first so how it's possible that this thing
00:03:13 manages to kind of puckle of these calls into a single packet and get back the
00:03:19 data right uh and yeah right now I'm going to prove
00:03:25 you this so that's the real qu of UI component that renders the list of items
00:03:31 and basically all it does is it gets the list of IDs and well puts them into your
00:03:37 model and like when the model is rendered uh so the next component that's
00:03:42 the component that renders the item it gets the data for the item by uh well
00:03:48 basically it's ID so as I said there is a clear data dependency nevertheless
00:03:54 what you saw is like it's real uh a single uh round Tre to the server
00:04:01 um so you may think that this is kind of fictional scenario right and it's a small sample but that's the real app uh
00:04:08 actual chat the app that we built and it's built on top of fusion so it sends
00:04:15 around uh 1300 calls uh when it starts or reconnects at least for my account
00:04:23 right uh I have a decent number of chats and stuff like this and um it needs
00:04:30 approximately 15 messages to kind of get the data for them typically uh and it's just 10 kilobytes
00:04:37 of data on reconnection and uh yeah it supports offline mode as well which doesn't require any extra code so
00:04:43 basically if you start without internet connection it's still going to render nearly the same
00:04:49 stuff uh and that's the code from actual chat you you can instantly spot that the
00:04:56 code looks weird right I mean okay like stuff like this you maybe can
00:05:02 run it locally but like it doesn't seem like you can do this with uh on the
00:05:08 client side assuming that most of these calls are going to the server side and like basically trigger some kind of RPC
00:05:16 uh nevertheless that's the real code and moreover this code like actually uh so
00:05:22 it triggers one of frequent animations uh I'll talk about this a little bit
00:05:28 later so that's the repository uh that's uh where Fusion lives and uh uh the
00:05:38 original uh so originally it was called as a Steel fusion uh I started the
00:05:45 project while I was a CTO at service Tian and I think I left during one year
00:05:51 after that um I contributed to the original repository for the next I think
00:05:57 couple years but then we decided to basically start maintaining our own fork
00:06:02 and that's the address of the fork uh so
00:06:08 uh yeah the reason why it happened is like I was basically the like almost uh
00:06:14 exclusively the only contributor there so uh it makes sense actually
00:06:21 um now I'm also known for some posts on medium uh fancy comparison of Go versus
00:06:29 C I mean in reality it's very in-depth comparison so if you are interested and
00:06:35 definitely check this out and like most of my posts are uh kind of circling
00:06:40 around uh performance uh and do map um so as I said I'm also known as a
00:06:49 creator of actual chat um it's a fancy chat up that
00:06:55 uh allows you to talk uh in like uh
00:07:01 really talk and we provide both instant transcription and deliver your voice so
00:07:06 basically every chat is kind of like a walkie-talkie where people uh can talk
00:07:12 but don't have to listen all the time uh and uh yeah they can join at any moment
00:07:18 uh continue conversation by typing or just uh well telling what they want to
00:07:24 say okay and uh uh yeah uh I think I
00:07:29 think we bet on one simple thing that like many people actually don't like to type I mean think about your
00:07:36 grandparents or like young children or uh situations where you it's just not
00:07:42 convenient to type right and U uh we basically mix these two experiences into
00:07:49 a single medium typing and talking um there are a few different
00:07:56 versions of this app you can download any and uh in any other sense it's more
00:08:02 or less uh like normal chat so um it
00:08:08 should be a good Feit for like either family chatting or like a small team where conversations are
00:08:14 frequent okay and now we are going to see the first demo like the first
00:08:25 example so um that's how actual chat works you
00:08:33 press this big recording button and start talking and everyone else who sees the same chat they see the transcription
00:08:40 and can listen to what other person says but like in reality uh yeah if you want
00:08:47 to respond you typically just respond and uh uh that's it so I'm going to talk
00:08:53 about this little button you see it's spinning right now um probably yeah I'll have to to
00:08:59 replay this part so this little button uh it spins
00:09:05 when someone else talks in uh the chat
00:09:10 you uh in in the chat you are in right so
00:09:17 it's a fusion component and all of them inherit from computer State component uh
00:09:24 the model uh is declared right here the model I mean the data that uh basically
00:09:31 this thing uh produces to render uh itself and uh that's the key method so
00:09:38 compute state is a method that exists in every computer State component so that's
00:09:45 the DAT compute computes and we are going to focus on is animated property
00:09:52 here or flag uh as you see like the way it produces this uh flag is first it get
00:09:59 gets uh chat audio state from chat audio UI well basically it's clear that it's
00:10:08 uh some uh kind of state that describes what what's going on with audio right
00:10:14 now uh is something Plank and so so on so as you see first it checks that like
00:10:23 uh you aren't listening right now which means that like this button is depressed
00:10:28 uh sorry yeah uh not pressed uh and then we get uh information about the current
00:10:35 chat uh get last text entry there see if it's streaming if it's has an audio
00:10:41 entry right and if that's the case then we get uh your own author in this chat
00:10:50 and uh check if the message is basically not originating from you so if like
00:10:56 someone else is talking then we start any so that's the code like and I think
00:11:04 what's unusual here right is that I mean okay like if you have all the data
00:11:09 locally then this code may work but in reality it works on the client nevertheless the code is kind
00:11:16 of it's it's weird it it looks like everything is like literally every bit
00:11:23 of data uh exists on the client right so why real time is
00:11:30 hard uh it's hard not because uh like just
00:11:36 reporting changes is something that's complex it's hard because you usually
00:11:42 have tons of different components right uh which report the state changes and in
00:11:49 the end you need to combine a single state for example you show the one you
00:11:54 show in the UI um and you need to make sure that the the single state is eventually
00:12:01 consistent the changes there are displayed in the right temporal order and so so on and that's the part uh
00:12:09 which is hard to get right uh
00:12:14 overall you need some uh framework and some set of core
00:12:20 principles uh that uh allow you to build all of that uh otherwise it's going to
00:12:27 be extremely complicated and let me show you why so
00:12:33 um let's say we want to like uh approach real time uh like we normally do so
00:12:43 let's say we have an API which returns a single item right and we want to render
00:12:50 it and then we want to observe for its changes and render each of these changes
00:12:57 right so that's the quote we probably would write in this case uh the only thing that's missing here I guess is I
00:13:04 forgot to write state has changes uh somewhere here
00:13:09 right well uh reality is very different uh like there are many problems in this
00:13:17 code and uh yeah right now I'll show you some so first of all we need to
00:13:26 unsubscribe from like receiving changes at some point so we can do it by
00:13:32 implementing I disposable here right and like implementing some sort of cancellation token we pass to observe
00:13:40 changes which is going to abort in the end and unsubscribe but like another problem is
00:13:47 that we need to call this method first uh and only after that call this one
00:13:52 because otherwise we may miss some changes uh and uh
00:14:00 so another problem is that this code doesn't do anything in case we
00:14:06 disconnect basically doesn't handle the situation with disconnects and
00:14:11 reconnects right and we also didn't touch the code on the server side because observe item has to be like
00:14:19 nearly as complex and as the code here actually maybe even more because you may
00:14:24 have a mesh of servers on the server side and state might be
00:14:30 um composed as well so um uh that's nearly the scenario we
00:14:38 have to deal with right and what I shown you here is like I didn't even touch the
00:14:45 piece where we combine a state from like multiple sources uh so even this part I mean when
00:14:53 we deal with a single Source it's kind of complicated already right and uh
00:15:00 these complications or like complexity that we get is what uh what we want to
00:15:07 avoid by all means because uh like
00:15:12 complexity I mean it's good to some extent but like uh it's well known that
00:15:20 that's sort of uh sorry the source of uh well the worst problems you may F face
00:15:27 in especially in the kind of second half of a lifetime of any product uh and it
00:15:34 skills not just products but the societies so you may find some
00:15:40 interesting analysis on this on the web okay okay so uh what is
00:15:47 fusion fusion is um distributed State Management obstruction which kind of
00:15:54 views the whole state of Europe as something it manages
00:16:00 uh that includes the state that's Exposed on the clients on the servers on
00:16:06 backends basically it connects all these pieces together and make sure that like
00:16:12 they get all the updates in real time uh
00:16:17 interestingly it's um it also solves many problems which don't look like even
00:16:26 related to uh real time for example caching uh well and uh
00:16:34 that's because like you have a perfect caching right you need to evict a stuff
00:16:41 from cash at the right moment I mean ideally as quickly as possible and uh to have this part you
00:16:49 need something that tells you that like this thing changed so that's how it's related to real time then um it's also
00:16:58 related to uh mobile apps and like reducing the network traffic basically
00:17:04 being very savy on network traffic uh because again uh if you know that
00:17:12 certain thing still stays the same you don't have to request it again from uh
00:17:18 the server uh it's also related to uh monoliths and microservices basically it
00:17:24 allows you to build a monolith that is extremely easy to transition to
00:17:30 microservice architecture and yeah I'll later I'll explain why and um like as
00:17:36 you saw already right uh another interesting piece is that like the code you write with Fusion looks kind of
00:17:44 almost normal uh it looks almost exactly like the code you would write but
00:17:50 without Fusion so that's a cool part because it's quite readable quite clean
00:17:55 and uh easy to understand well and finally it's uh really kind of Blazer friendly
00:18:04 there is a very thin integration with blazer but basically it's a natural fit for Blazer ups and uh yeah one of again
00:18:13 kind of fancy consequences is that you can build um server side Blazer UI and
00:18:21 web assembly UI for hybrid UI and it's going to be the same code like you don't
00:18:26 really need to make any changes begin to work uh that's how it works in actell
00:18:32 chat and in all Fusion samples so you can switch them from server side Blazer to web assembly basically Standalone
00:18:39 client or client running on the server and it's it's the same thing okay um so now I'm going to show
00:18:48 you one of U kind of uh bigger samples uh from Fusion it's
00:18:56 called Todo up and uh I'm going to um basically my goal is to
00:19:04 illustrate how uh all of that uh
00:19:09 basically impacts on um certain behaviors of the app so let's
00:19:19 start let's start the app right
00:19:29 so I already have a couple windows open you see that it just reconnected and I
00:19:36 am authenticated here well let's item
00:19:42 three and do the check box so you see that basically all these properties they
00:19:47 update and this one is by the way working Blazer server this one is web
00:19:53 assembly let's switch this one to web assembly as well
00:19:58 so you see they work in sync right now I'm going to sign out just to show how
00:20:05 it works and or sign in so it basically does this in both
00:20:11 windows okay um sign
00:20:17 out um so um there are two versions of
00:20:22 uh this uh to-do page and uh um the
00:20:28 version two is the one we are going to uh study and
00:20:36 um yeah let's have one item here for now
00:20:43 so um yeah I'm I'm going to stop the up
00:20:50 right
00:20:57 now so um let's open these pages
00:21:03 right to do page one and is to do page two
00:21:09 right um so what's the difference the difference here is uh how like computed
00:21:18 State uh is implemented um you see that uh on page
00:21:24 one it basically calls uh some to-do service and gets all the items and the item here
00:21:33 is to- do item if we click on it we will see that basically it contains
00:21:39 everything right then uh if we go to to do page
00:21:44 two uh you will find out that this thing
00:21:49 fetches IDs of the items and its model it uh uh exposes these IDs so uh the
00:21:59 code that renders the page uses to- do item view which gets the ID if you click
00:22:06 on to do item view then you will see that its compute State method uh
00:22:13 actually gets the item by this ID and renders it and uh as for the first page
00:22:22 it's a little bit different there it use a different component to render the item
00:22:28 call too item row you and this one doesn't fetch anything it basically gets
00:22:34 the item and renders it so uh I think uh what's reasonable to
00:22:42 ask right now is like um what happens uh under the hood right what kind of uh
00:22:49 requests it sends to the server and U like how basically it gets all the data
00:22:57 so we're going to run it again right now and um I'm also going to leave just
00:23:04 one of these windows and open
00:23:09 Chrome inspector okay
00:23:15 okay so first let's refresh the page oh
00:23:21 my God let not to do uh let's refresh the page right
00:23:30 uh and how do we clear everything
00:23:42 here okay now uh
00:23:50 let's let's retry okay so it sends um
00:23:59 so it doesn't uh use HTTP client to send all these requests it uses custom
00:24:06 protocol and that's why I basically enabled some logging and showing you
00:24:12 what kind of um calls it makes uh so uh that's the first call uh
00:24:19 the first call is handshake right then it uh calls get summary that's this
00:24:25 component right then Authentication part like pulls I think that's to render this
00:24:32 component uh pulls some data you see that uh get summary now got a
00:24:39 response uh then uh I guess uh authentication get user get a response
00:24:46 and um I think in the end well uh let's
00:24:51 focus on list this yeah so it uh I think
00:24:56 all these calls if you look at the like timing of all these calls it basically like sends all these calls almost
00:25:04 simultaneously right and then gets the first kind of chunk of data let's add
00:25:10 one more item two and I want to add also item three and item
00:25:17 four so let's uh let's uh do uh refresh
00:25:23 once more so you see that uh like
00:25:30 as soon as uh list IDs returns uh the
00:25:36 result it sends like all these get methods like I mean go get requests for
00:25:42 the item data in parallel and uh uh like gets the data right if you go to tut2
00:25:49 page two and press refresh you will I think
00:25:55 um wait uh
00:26:03 sorry so you will basically see the same uh output so it's like list ID returns
00:26:10 then it sends a bunch of calls to get the items right and as for everything
00:26:16 else so basically they Works in a very similar way
00:26:21 right okay so um
00:26:28 now let's uh also look at the networking tab right and um what I want to do here
00:26:36 again let's uh clean blog so I want to show you how basically many exchanges
00:26:44 happens here so these first two are handshakes then that's the request that
00:26:51 combines a bunch of calls and uh like get summary data user data I think and
00:26:56 other stuff and this is the request that uh I think gets all the
00:27:02 items so what's interesting is that like from the networking standpoint uh it
00:27:08 looks like uh like accept handshake just two exchanges I mean just two like round
00:27:14 trips happened right okay um and yeah by the way I'm so
00:27:21 I'm going to uh now I'm going to show you
00:27:26 uh the
00:27:33 um the most option sorry optimal version of this
00:27:39 exchange uh so uh what I did uh before
00:27:45 running this sample is I disabled one of services here and um basically the
00:27:52 service uh is called uh local storage remote
00:27:58 computed cach you can uh click on it it's implemented right here it's a very simple service
00:28:05 that like basically extend extends remote computed cache so you can have a
00:28:11 custom version of it better one than this one but uh so let's see what's
00:28:18 going to happen uh once I run the app with this service
00:28:39 so again cleaning V refresh we need updated
00:28:45 client and you see the first refresh it's nearly the same exchange right so it's
00:28:50 basically um let me actually do one interesting
00:28:57 thing so I'll change the protocol as well right now and uh we'll use the protocol
00:29:06 that at least uh shows uh the names of the methods it uh calls right in so
00:29:13 basically the one that was used here it's like extremely efficient version and it uses um anyway that's I guess
00:29:23 I'll explain it later but for now just let's switch it to uh um let's switch
00:29:29 the client to a less efficient protocol in terms of like the amount of data send
00:29:36 a little bit less efficient so I refresh and click here there is
00:29:42 literally so this is a handshake request response right but this one I mean this
00:29:50 message it combines literally everything uh I mean we see that there is a get
00:29:56 summary get user and even uh to do API get uh
00:30:05 methods like basically get list IDs uh so literally everything
00:30:13 uh is combined into a single uh Network
00:30:18 packet and moreover that's how the response looks like so the question is
00:30:24 like what's going on right uh how it's possible that this thing um literally
00:30:32 just makes just a single network round FP and gets all the
00:30:37 data and uh yeah let me show you uh what happens
00:30:44 under the foot so if we go into the application local storage so I shown you
00:30:50 that like we now use cash and uh what
00:30:55 actually happens is that Fusion CL basically emulates
00:31:02 the connectivity with the server and like when it gets a request to call one
00:31:09 of remote methods if it has a value in its local cash then it immediately
00:31:15 responds and uh at the same time it validates it against the I mean
00:31:22 basically sends a request to the server which uh checks if the value that client
00:31:29 has is still the same and sends back the data only if it differs otherwise it
00:31:34 responds that hey your data is still correct um so
00:31:41 um now so so um let me clear it uh and uh just again
00:31:51 to show how the exchange starts so that that's
00:31:58 what happens when you have an empty cache right basically it sends the first Chun of calls the once it gets all in
00:32:07 like in a single Network bucket uh uh when you refresh the page gets a
00:32:14 response and then sends next Chun of calls okay
00:32:23 um so uh let's check a few uh things here first let's see if it's going to
00:32:30 work if I disable web sockets uh like disable web sockets
00:32:37 completely so what okay should be use
00:32:42 web soet right
00:32:49 mhm okay so we will disable this
00:32:54 part and I'm yeah let's restart the
00:33:08 server so you see that it's unable to reconnect right right now basically if I
00:33:14 click reconnect nothing happens it can't reconnect uh and if we go to console
00:33:22 then uh well it's going to dump your messages here um but like
00:33:31 it kind of pretends like it works uh I just clicked here right and it can
00:33:37 basically run any actions but nevertheless right now it's kind of let
00:33:45 me show you I can even switch these Pages give it you authentication like basically it behaves
00:33:50 like it works let's refresh the page so I just clicked refresh it still
00:33:58 can't reconnect it basically um yeah it dumps all these zor messages
00:34:06 because it can't reconnect uh but nevertheless I still can uh kind of
00:34:13 scroll through the app and so that's what uh this remote computed cat does
00:34:20 basically emulates the presence of a server uh the server that responds
00:34:25 instantly with the last version of well whatever data you requested that it
00:34:31 knows on the other hand since like and you will learn about this later in this
00:34:37 video but since everything is designed that basically every piece of data May uh kind of become stale and report that
00:34:45 it has to be updated and like uh this emulation is possible because uh well
00:34:51 literally if server or like if the client sees that the new value on the server is different
00:34:58 uh like for example after reconnection right then um it will
00:35:07 uh it will run a process that will invalidate it here and like recompute
00:35:13 and fetch the new data so basically um all of this uh kind of works in tandem
00:35:23 with uh this mechanism that allows uh Fusion to distribute the information
00:35:31 about changes okay let's check one more thing uh here
00:35:36 so right now uh so right now uh we're going to leave this
00:35:43 client operational and we going to change the back end on the server side
00:35:49 and restart the server uh what like supposed to happen right uh
00:35:58 is that like okay there is a different server different band so it has to
00:36:03 update the data because like it can cannot expose this data anymore um let
00:36:11 me do this so first let's reenable web
00:36:18 circuits and run it I just want you to like see that the client will reconnect
00:36:27 in this case is and like basically will continue working as it's supposed
00:36:33 to just connect it yeah so the data is there you can make
00:36:39 changes now now I'm again stopping the server you see that okay
00:36:45 disconnected and um so let's replace
00:36:52 uh uh so you see that like the service that's uh um I2 do API is the service
00:37:02 that uh is used on the client side and
00:37:08 uh there is a server for this service right so that's how the server is
00:37:13 registered Fusion at server and that's the service and that's the
00:37:19 implementation so we are going to swap it right now with this thing and uh so
00:37:26 this thing goes to the dat database and like it's even more complex than that and I'm going to like use right now a
00:37:33 completely different implementation and uh so let's start the
00:37:39 server and see what's going to happen here right just connected so you see
00:37:44 that it like refreshed everything right now basically if you look here uh it
00:37:52 sent all these calls that are necessary to refresh the data right
00:37:58 and uh so which one is spending uh this one right we are
00:38:05 looking for it basically tries to connect I guess too many
00:38:14 times I'm not okay finished finished
00:38:22 finished yeah I'm not sure like uh how to find the right web
00:38:29 circuit connection now but I guess it's fine so the point was that like it
00:38:34 changed the state okay let's add a bunch of items
00:38:41 here well no wait uh so we need yeah we can't use in memory service
00:38:49 for this it's going
00:38:54 to and so um my point is it works but if I shut
00:39:01 down the server right then um it's going to uh well um the state will be uh will
00:39:15 disappear so um let me quickly get back to the old
00:39:23 version H it's it's by the way it's wait wait wait wait uh so it's a fancy thing
00:39:30 it just reconnected and uh shown the Old State yeah I wanted to show like what's
00:39:36 going to happen here so uh now the interesting question
00:39:42 is so it sends uh a bunch of calls right when it starts right and uh I think the
00:39:50 question is like if this state is catched what part of logic is
00:39:55 responsible for sying that cach State and right now I'm going to show you that
00:40:01 like uh it's uh okay so I just refreshed oh by the
00:40:09 way that's that's also interesting to see it right so that's what what happens
00:40:14 in presence of a cache so you see that like it literally throws every call like
00:40:21 in parallel before it even gets the response it's like get summary and and
00:40:27 it looks here that it sends the Gap all first it just kind of goes through first right in reality it requested this thing
00:40:34 it responded immediately then it sends uh like it requested all these things and like uh basically that's how it gets
00:40:43 this single packet uh to send on the server because like all these calls they
00:40:48 are literally produced synchronously and uh they are ready to
00:40:54 send basically at almost the same time uh so let's let's uh just modify the UI
00:41:03 code and remove this uh thing and I think the expected effect is that we should not see these calls as well right
00:41:17 um so we need let's do this on Tod do page two uh which features the IDS
00:41:25 right um
00:41:41 I think it's fine uh let's start
00:41:48 it so right now I have to refresh the client and
00:41:55 uh I click control r so you see that uh there are no calls to
00:42:04 both list IDs and get uh like uh uh I
00:42:10 mean to do api. getet if we go to
00:42:15 another version of this page and we didn't modify it then like that's what
00:42:21 going to happen it sends all these calls and if you will go to uh networking tab
00:42:31 you may see that I think all these calls were sent so this is list this get get
00:42:40 get they were sent at once and uh yeah uh in terms of
00:42:48 responses uh so they came in two different pockets and that's basically
00:42:54 depends on server right if server can produce the response syn noly synchronously like because data is
00:43:00 available and it does it otherwise it may send send a bunch of buckets
00:43:06 okay so a lot of fun stuff but I think the main conclusion here is that like
00:43:12 it's extremely efficient in terms of getting the data via Network and uh like
00:43:19 even packaging it into uh basically the least possible number of Transmissions
00:43:26 not exactly least possible but quite close to that okay now we are going to see how it
00:43:35 works so basically what is the code that's responsible for all these real time updates in this app and um like
00:43:44 look a little bit deeper so far we saw mainly the UI code right and uh we are
00:43:51 going to look into the server site code okay um
00:43:59 so I'm I'm going to um basically undo some of my changes
00:44:06 here and what else what else let me see
00:44:11 yeah I think that's the only change that I I made oh yeah so like let's keep this
00:44:19 protocol for now so let's start from
00:44:27 uh to- do page one the one that basically fetch everything with this
00:44:36 call so what is todu todu is to
00:44:42 do uh let's see how this thing is registered
00:44:48 right um You can easily see that it's
00:44:53 registered as a compute service which is scoped scoped means it lives in like
00:45:01 Blazer scop so basically it's a client side service like we are talking about the Blazer um apps
00:45:09 right uh so uh and uh you see that it was uh
00:45:16 registered as compute service and uh it also kind of extends this weird
00:45:23 interface I compute Service uh so it's a tagging interface well
00:45:32 for yeah the comment is wrong here but it's tagging interface for comput
00:45:38 service yeah uh so basically I think it's it's a copy from RPC service requ
00:45:44 iing proxy probably from one of these interfaces but the point is like uh this
00:45:50 is a tagging interface you don't have to implement any methods it just like tells
00:45:56 uh Pro generator that this thing needs a proxy and I'll talk about this later
00:46:02 then so we were calling this method here right and uh uh what it does it calls to
00:46:10 do API list IDs then it for each of these IDs it calls this method so
00:46:16 basically gets the item collect is Task one0 basically it's like a we can
00:46:22 rewrite it as T all and
00:46:28 um something like this wait it's it's uh
00:46:36 well it here something like this it's the same code
00:46:42 uh I'll return it back collect is just a little bit more flexible thing
00:46:49 um so what you see here is that like this
00:46:56 thing literally calls uh to do API and gets all the data from it kind of
00:47:01 rearranges it right pugs it into uh basically uh a single array or list
00:47:09 right and um returns it now uh so what is to- do API um Tod
00:47:16 do API is um an interface let's see how this thing
00:47:23 is registered and uh um well you can find
00:47:30 there is a number of registrations but we need the one that's uh registered on
00:47:36 the client that's the thing basically it's a fusion client for this uh
00:47:44 service if we click on it then we see that it has well add door update and
00:47:50 remove methods uh like Let's ignore this command Handler thing but again we see
00:47:56 this comput method compute method compute method on get list this and get
00:48:02 summary so that's the method that uh that's
00:48:08 basically Fusion method the method that's kind of backed by Fusion uh
00:48:15 logic um and
00:48:22 um let's find the server right for this client uh um so I'm going
00:48:28 to uh do the same thing and that's how it is registered on the server site at
00:48:36 server Tod do API let's go to the to-do
00:48:44 API um so list IDs here uh
00:48:51 um it's pretty simple it calls get folder uh and pass the station here
00:48:58 right and then calls back end uh passing
00:49:03 the folder so you may think of this as uh so uh to do API is basically a
00:49:11 front-end service a service that is responsible for kind of rewrapping what
00:49:18 backends can provide but uh running extra security checks and basically uh
00:49:25 kind of filtering out what you can't access right and what it does is like uh
00:49:30 basically if you look at get folder method there you will see that uh it
00:49:37 resolves the user uh from s and so ignore the tenant part but I think
00:49:44 basically if the so this thing is going to be empty uh in this case because we
00:49:50 don't run it in multi- tency mode but yeah sample can be executed in multi
00:49:55 tency mode as well so this thing is going to be empty uh this whole piece
00:50:02 right and ultimately it like basically returns a prefix to some key value store
00:50:09 right which is either this or that if you are dependently on whether you are
00:50:14 authenticated or not right and then for this prefix or folder it uh so oh sorry
00:50:23 list ID SCS uh well method providing
00:50:28 this folder so you you can think of it as like basically this part uh did some
00:50:33 Security checks right and kind of rout at the user to the right location on the
00:50:38 backend storage and then like it calls the back end and gets the data and uh um
00:50:47 let's look at this thing right so theend is also compute Service uh and uh and by the way uh let
00:50:55 me show you one other I think get user is also compute service
00:51:01 so um you see that like nearly every call that they make is uh a compute
00:51:09 service method or a method that calls some other compute service methods like like this one it doesn't have this
00:51:14 compute service thing oh let me clarify one thing uh so there is no compute
00:51:20 service attribute here but it's inherited from the interface kind of inherited because it's here okay so the
00:51:29 point is uh the point is uh so let's go to the list on the back end and go to
00:51:37 now I'll just use I'm going to use this very way simpler navigation and just
00:51:42 give to the implementation oh and yeah one of my old break points is here so if
00:51:49 you look here you will find out that like this code is again like almost
00:51:55 normal in terms of like what it does it basically gets the DB context right
00:52:02 using some uh well um additional service
00:52:08 but uh ultimately it gets the DB context and then just Runing query and gets all
00:52:14 the keys right uh maybe by like with some kind of
00:52:20 postprocessing uh so um what's unusual is I guess this part
00:52:28 right but that's nearly it so let's
00:52:36 um so the question is right what happens when we add the new
00:52:42 too item so that like somehow somehow this method gets called
00:52:48 again right and the answer would
00:52:54 be uh well yeah let's let's leave these break
00:53:00 points actually let's leave these break points um the answer would be this
00:53:10 piece uh so any method that makes some change it has a block like this uh and
00:53:20 um this block is responsible for uh running socalled invest validations
00:53:27 basically whatever method is called here with whatever arguments
00:53:32 passed um the result of this method if it was cached before then it's going to
00:53:40 be you you may think of it as if it's going to be evicted from the cach so in
00:53:46 reality it's not exactly like this and it's it's a little bit different and but
00:53:51 you may think of like what happens here as I just described basically if you
00:53:57 call uh for example get summary method with some folder here and default is for
00:54:03 cancellation token I just want to show you so you can remove it but like it's
00:54:08 going to highlight it right so okay uh I mean the writer is going to kind of
00:54:14 complain uh so let me show you one thing I'm going to comment out this piece right now and
00:54:22 uh now when I will be removing an item summary is not going to
00:54:29 update so since we changed just the server right now let me see right so
00:54:38 that's the only change that we've made then uh I don't have to update the client sorry that's not the that's not
00:54:47 what I want to show okay so summary you
00:54:53 see that like right now it's updating the delay there is intentional so it's not like there is a protocol delay or
00:55:00 something it's basically one of settings I'm not going to show like uh well maybe
00:55:07 I'll show how easy it is to like control all these delays but the point is so
00:55:13 right now you see that summary gets updated now let's try to remove
00:55:18 one and you will see that like it wouldn't change and moreover
00:55:26 uh it will never change like uh basically unless uh I mean I can call
00:55:32 like state has changed inv validate recompute I can open another version of
00:55:38 this page and it's still incorrect because uh because no one told
00:55:46 Fusion that summary has to be invalidated uh so that's that's how it
00:55:53 works but if we will add the a new it or like edit this one for
00:56:00 example oh no so on edits it's not going to be updated but when we add an
00:56:09 item it it's again in sync right now so um uh let me get back to
00:56:19 the code that we we're playing
00:56:24 quiz so get some I think the reasonable question to ask is like why there is such a weird syntax
00:56:32 and what actually happens because it's like it feels
00:56:38 like uh this code it kind of cannot run
00:56:44 once right I mean it feels like this method runs the number of times and
00:56:51 that's that's what actually happens uh so when this method is executed for the
00:56:57 first time or like when basically the original call is made it goes through
00:57:04 basically this part and uh this condition is false
00:57:11 but uh once it completes and once the transaction uh is getting committed and
00:57:18 that's why by the way it uses a special call here to get uh Deb text uh such DB
00:57:26 context or like basically it tells that like okay this method makes changes and
00:57:32 it needs a special DB context that is going to be uh I mean the transaction is
00:57:38 going to be created there and a bunch of other things that kind of make this Machinery work but ultimately in the end
00:57:45 when the transaction uh is committed it's going to run this piece and it's
00:57:50 going to run it not only on like this single machine but on every machine in
00:57:56 the uh cluster that uh like talks to the same
00:58:01 DB uh so basically uh it's uh like another aspect
00:58:09 that kind of helps uh this distributed Mode work uh I mean on the server side
00:58:15 it doesn't even have to kind of sync something over the network protocol or
00:58:22 like basically there is a different uh approach that allows different servers
00:58:28 to uh invalidate uh a part of their State uh
00:58:33 when you make changes on one of these machines and it's extremely reliable uh
00:58:40 like uh uh I think well I mean the simple explanation would be that it uses
00:58:47 outbox pattern but in reality it's like a little bit more complex and
00:58:53 advanced um okay
00:58:58 um and yeah one thing I want to show you
00:59:03 is API so if you like don't involve the
00:59:09 DB and use more kind of low level approach then uh that's the code that
00:59:17 actually uh allows you to invalidate something uh you uh run this thing in
00:59:25 using log and whatever you call inside is uh getting
00:59:30 invalidated so uh in this case basically the block like this is executed by one
00:59:39 of pipeline handlers for this command like any command actually basically
00:59:45 detects that okay there is an operation that was committed so I have to run this
00:59:50 command G but in the invalidation mode that's nearly how it works uh um let me
00:59:57 show you the last thing uh right now so I'm going to run uh Aspire host for uh
01:00:06 this sample and
01:00:12 uh it is going to be even more
01:00:18 interesting I don't want to open it here okay let me open it in Chrome as
01:00:30 well oh wait I need this
01:00:36 thing okay so right now this thing starts started like six
01:00:45 hosts uh three API hosts on five, five 6
01:00:51 and seven and for each of these host hosts it started back end hosts so
01:00:57 backend hosts they run a backend API host they run to do API and API talks to
01:01:05 a backend on corresponding host so um
01:01:11 now let's do
01:01:19 well we're going to close this thing and yeah
01:01:27 and we're going to go to another post here so remember they still talk to the
01:01:36 same I mean they still use the same DB and what I'm going to show you now is
01:01:41 how these distributed inv validation on back end for so you see that like this
01:01:47 is a different front end host and this is like also a different front end host
01:01:52 they use different backend hosts but in the end they use the same DB so what's
01:01:58 going to happen if I click here
01:02:03 oh
01:02:09 um six what happened with this thing
01:02:27 okay now let me show you the last uh piece about this sample so I'm going to
01:02:34 start Aspire host and
01:02:39 uh yeah um not here so I already opened it here
01:02:50 will it yeah it works so um let me
01:02:56 let me get full screen for now so uh Aspire host started six hosts
01:03:07 uh basically three API hosts and three backend hosts and each API host like
01:03:14 this one for example running on 50005 Port is tooking to this back end
01:03:20 and like basically to do API Services working here and uh uh it uses backend
01:03:29 as a fusion client so I to do backend which uh actually uh is hosted
01:03:37 here and this service uses this backend and so so on
01:03:43 so now uh yeah let's refresh both
01:03:50 things so you may notice that ports are different here right basically they use
01:03:56 different front ends so the different apis um API hosts and these API hosts
01:04:02 they use different backhand hosts and the only common thing they use is
01:04:09 database uh so are they going to
01:04:15 sync well as you see they do uh and that's how this distributed invalidation
01:04:22 on backand Works uh like yeah they stay in sync as they are
01:04:31 supposed to be um so let me you can Swit switch this to server like really
01:04:38 doesn't matter what you do uh so let's
01:04:46 um let's do one other thing
01:04:52 sohm you can find traces here for any host but I'm going to focus on metric
01:05:00 and we are going to uh observe metrix from
01:05:10 the let's observe Matrix from uh this back
01:05:15 end and let's go to call duration call count right so uh
01:05:24 list IDs uh basically it gets called when we
01:05:30 change something right I mean in terms of number of items in the
01:05:36 list Let's uh okay I can't click here yeah so I just removed we get another
01:05:43 call so the interesting question is what's going to happen if I
01:05:51 um click refresh here that's the first thing will it call back backend uh once
01:05:57 more cuz like I mean in in the normal situation right uh like this thing will
01:06:04 try to get the data and will hit the back end again so I'm refreshing
01:06:11 it refreshed refreshed it doesn't hit the
01:06:17 back end right uh the reason is that like the value the value that it gets
01:06:24 it's catched on the front end let's kill the back
01:06:31 endm so we go to resources po one backend can we kill it
01:06:39 [Music] somehow let's try
01:06:49 to well
01:06:55 looks like yeah I can't kill it here
01:07:02 unfortunately um yeah I don't know how to like U but
01:07:09 my point was that like if I kill the front end then uh of course uh it would
01:07:16 get the heat on the back end so I can show this
01:07:21 unfortunately okay so uh that's uh the demo part and let's move
01:07:31 on so we went through the most complex part and uh now uh I'm going to explain
01:07:41 how all of this stuff works so think about how you build uh binaries
01:07:51 uh now most of uh build tools like make uh Ms build uh net build whatever they
01:08:00 are incremental Builders which means that they uh build the final binary by
01:08:07 building some intermediates from basically the very low level inputs like
01:08:13 well files or like whatever they reference and uh so imagine that you
01:08:21 change one of these files right for example services. CS
01:08:26 then like whatever depends on this file kind of gets you you may think of like
01:08:33 what incremental Builder does is that it kind of marks everything that depends on this file as stale or like
01:08:41 invalidated and uh uh so for example if you want to build this thing up. ex
01:08:49 there right and it will rebuild server. dll services. DL and so basic basically
01:08:55 whatever was uh like on this path right and uh as for the rest it will simply
01:09:03 reuse that right for example uidl is going to be reused and that's exactly
01:09:09 what Fusion does uh like uh it might be unclear how it's relevant
01:09:17 to what you saw but Fusion does exactly the same thing but for your functions so
01:09:24 you like may look at your build processes function calls like where the
01:09:29 argument like that's the function right you call and that's the argument and uh if
01:09:36 Fusion gets a chance to transform these functions to such incremental Builders
01:09:42 then like you would get exactly the same thing as incremental build there is one of samples by the way in I think it's
01:09:52 uh probably hello world sample or something like this it does exactly this in like but like simulating exactly this
01:10:01 but on top of fusion yeah or like uh so I think that's
01:10:10 uh the same graph but with just different methods and different
01:10:15 arguments so that's how Fusion works and I
01:10:21 think the only thing you need to
01:10:26 kind of add to so you already can like build or
01:10:32 describe such graphs in your programs right by just calling functions the only
01:10:38 missing piece is this like uh inv validation concept and I already shown
01:10:44 you how it works in case with Fusion you basically use inv validation block and
01:10:50 call functions which has to be marked as stale with like the arguments you pass
01:10:56 there so that's nearly how it works now uh
01:11:02 yeah and obviously like if you think about um I mean any modern app then like
01:11:11 in reality you can think of it as you simply rebuild the UI when like by
01:11:19 calling functions which call other functions and so so on and uh so if you
01:11:24 have this feature right that basically marks uh certain call as stale and like
01:11:32 you can rebuild the UI so uh as a reaction to some
01:11:37 change okay so uh how Fusion works well it wraps
01:11:47 your functions into basically higher order function uh decorator uh uh that
01:11:56 adds this incremental build and caching behavior and uh a very
01:12:03 very or like extremely simplified version of this decorator would look
01:12:09 like this it produces a key from function and function you call I mean
01:12:17 and it's input input includes This and like all the other arguments right then it looks into some cach trying to get
01:12:26 basically a box that kind of describes previously computed value let's call
01:12:32 this boxes computed right and uh well if it gets one it uses it uh otherwise
01:12:41 locks uh well this key and tries to get it once more so it's basically a double
01:12:47 check locking right and returns it if it finds it but if it can't find such a box
01:12:54 then it basically it produces it and um uh so here like it basically creates the
01:13:01 Box exposes it and then calls the function that is supposed to
01:13:08 uh compute the value for this box and uh so
01:13:13 interestingly uh if during the computation it gets calls to similar
01:13:19 functions right then they will resolve with this use or this use or this use
01:13:24 and since we exposed the current box and basically this thing allows them to
01:13:30 register as dependencies in the current box and that's how it builds this graph
01:13:36 of uh basically cached computed values uh each time it computes something it
01:13:43 kind of updates or like rilds the small part of this graph so in reality it's way more
01:13:50 complex than this way more complex because like first uh well
01:13:56 uh you can't it's pseud code right you can write it on C and second is like
01:14:01 it's a synchronous it's truly threat safe and like many many other things but ultimately it's basically does nearly
01:14:09 this job okay and yeah if you think of like uh how so what happens with these
01:14:18 boxes over their lifetime or like what happens with computations right and so
01:14:25 Al you start the computation and get is result or error and like we can kind of
01:14:31 draw a separate part for cancellation on that net so it's like in reality it's
01:14:37 Herer but like special kind of here right and so with Fusion it kind of
01:14:42 extends this thing uh since this thing produces a box that sits behind the scenes and no one kind of sees it except
01:14:50 Fusion right then like B basically it Returns the value from this box but the
01:14:56 Box itself stays and uh at some point later it may become
01:15:04 invalidated uh so this is a very very ancient kind of Animation that I create
01:15:10 on like how invalidation works so that's why this part it's like it's totally
01:15:18 irrelevant uh right now it works a little bit differently but uh I think
01:15:24 it's kind good in terms of illustrating what happens under the scene when some
01:15:31 invalidation happens and then recomputation happens so we invalidate like let's say like one of low level
01:15:38 values for example like on back end right and it invalidates everything until the front end that depends on it
01:15:46 and then front end like decides okay I need to recompute this and then basically it rebuilds a set of nodes by
01:15:52 and some of these noes May reuse other computed values implicitly so you
01:15:58 like you don't have to do anything to for this to happen but like nevertheless
01:16:03 that's nearly what happens under the
01:16:08 food okay uh yeah so
01:16:14 uh we will skip this part because I already shown how it works uh and uh I
01:16:22 think uh we already kind of know what approximately happens when we
01:16:28 invalidate or don't invalidate things now
01:16:35 uh one other interesting part is like this Fusion client right so you saw that
01:16:43 um web assembly client talks to the server and servers may talk to other
01:16:49 servers like for example the backend um uh could
01:16:55 talk with the uh sorry the front end API service could talk with backend service
01:17:01 running on another poost so
01:17:07 um and uh the reason why uh Fusion uses
01:17:12 uh well basically a special client is that this protocol and that's
01:17:20 the protocol you kind of normally use for like any other RPC service it
01:17:26 doesn't work in Fusion case and you probably already know why it's not
01:17:32 enough for Fusion so uh you see that like we throw one message to send the
01:17:39 call and throw like the server responds with another message and delivers the
01:17:44 result in case with Fusion there can be a third message uh called
01:17:51 invalidate why I'm saying can be well because uh in
01:17:56 reality uh I think for a majority of data that leaves on the
01:18:04 client uh it doesn't get it uh even like
01:18:10 I mean every session so um just think about this like most of user data most
01:18:16 of like uh whatever you show it actually doesn't change so this part almost never
01:18:23 happens in reality uh but nevertheless the protocol has to support this piece right and one other
01:18:31 important thing is that like if you think about this uh it doesn't change
01:18:36 anything that this piece exist in sense that like okay you uh so instead of like
01:18:46 one one round trip you get like one plus maybe two uh Transmissions but in terms
01:18:54 of like it doesn't change the big picture basically and this message is extremely short it basically tells that
01:19:01 the call number three is now invalidated well and uh I think it worth
01:19:08 mentioning that Fusion protocol also supports this thing it's like it basically it's designed in assumption
01:19:15 that the client may have an offline cash for any result it gets so since this
01:19:23 part is is kind of is here right then
01:19:28 well basically when this message goes uh to the client it can evict the value from cash instantly right and uh
01:19:36 basically if you don't have this piece then your client side cash is kind of useless because it's going to return uh
01:19:44 well mostly it's going to return stale values I guess right and if you have this part on the other hand then like it
01:19:52 becomes well basically extremely useful and you still need some extensions to
01:19:57 the protocol right for example this kind of response much response that doesn't
01:20:02 send the data back right um to make it
01:20:08 work okay so
01:20:15 um and now I think uh that's
01:20:21 um like why this part explains why it's so efficient so if you think about the
01:20:27 call that uh your client kind of wants to make
01:20:33 right for example we want to get an item with certain ID right and if we think
01:20:40 about the chances of how this call is going to be resolved then like I think
01:20:46 the highest chance is that it's already computed on the client so basically the value is available right then like okay
01:20:55 uh let's assume it's not computed then maybe it can be computed from other
01:21:01 values on the client which are are already computed and okay if it's not
01:21:07 this spot then maybe okay we resort to RPC but it can be computed on the server
01:21:14 already and basically the same process repeats on server and like it may not hit the can server and so so on so
01:21:21 that's why uh like so if you think about this it's exactly what incremental build does and that's why um Fusion is so
01:21:29 efficient in terms of traffic in terms of like literally everything in terms of saving CPU Cycles Network traffic
01:21:37 literally everything
01:21:42 so it's kind of interesting to think of like how efficient uh
01:21:50 it actually is right um and like how it translates into the
01:21:59 number of calls per second for example or uh like so what's the speed up what's
01:22:05 the actual speed up right and uh so there is a test uh you can run it I'll
01:22:11 probably run it right now actually let me so what I want to run I want to run
01:22:19 let's run it in Docker uh yeah this this thing is fine
01:22:25 so I'm going to run it right now um yeah it's going to build but let me kind
01:22:32 of um quickly show you the
01:22:40 results so you will see near these results maybe
01:22:45 a little bit uh less impressive because I'm going to run it uh with Docker right
01:22:52 now and I'm also recording video I'm also um like I mean there's so basically
01:22:59 a bunch of things are running on my machine right now but the point is so if
01:23:07 you have a local Fusion service and it if it gets a chance to kind of cash a
01:23:13 large percent of uh method calls in this case uh so this test uh like basically
01:23:21 runs uh like uh a few hundred re ERS and the single writer that modifies
01:23:27 continuously modifies one random uh item so I think the chance that it kind of
01:23:34 gets uh basically if if it's about the local
01:23:39 service then most of these calls are going to be resolved from like cash right and uh so when it hits this happy
01:23:48 path scenario then it runs well 100 so
01:23:53 it's basically something like I think if you run it on a single core it's going to be around 15 million calls per second
01:24:02 per core in like uh my machine is more powerful but it's like I think 32 cores
01:24:11 in reality so of course it can't scale like uh with
01:24:16 literally uh no uh penalty but uh so it's uh 16
165 million calls per second now the interesting part is that
01:24:30 if you are going to use Fusion client for the same service and service is
01:24:36 going to be located remotely then there will be almost no change the reason is that it just doesn't send the call right
01:24:43 when it knows um that a given value is still consistent so like literally it's
01:24:51 almost identical number of calls per second but like when you use a
01:24:58 networking client Fusion client and that's why so remember the beginning of
01:25:04 uh this talk right I was showing you uh service from actual chat like sorry
01:25:09 small UI component from actual chat that renders the uh listening
01:25:15 button and the quot looks like uses just local stuff and somehow it works so
01:25:21 that's the reason why it works uh the reason is quite simple networking services like built on
01:25:28 top of fusion I mean the services CL networking clients right built on top of fusion they nearly as efficient as like
01:25:36 local services and I mean moreover they also cash calls so that's why uh like there
01:25:44 is no difference between using like a service that reides on your machine or
01:25:49 resides remotely and in most of cases there is like no
01:25:55 difference uh and that's why the whole UI in actual chat is designed like this
01:26:02 it's basically like just throws calls to different Services gets the data and
01:26:08 feels like like it doesn't have to do any extra to kind of efficiently process
01:26:13 it or uh react to something it just like sends the calls and gets the data
01:26:22 rewraps it and shows in right okay
01:26:29 Soh as for like some other results here uh so that's uh like uh so Fusion
01:26:37 Service uh versus the same service but without Fusion uh decorator or proxy
01:26:44 it's I think 1,000 times slower which is expected because this thing is go is
01:26:50 going to database each time you call it here then like a few other interesting
01:26:56 results is that like so this is a fusion networking client right smart client
01:27:02 that knows when a value is still consistent and doesn't send the call so
01:27:07 what if we replace it with like less smart client but based on the same
01:27:14 protocol that Fusion uses so this like I'm going to uh record a video dedicated to this
01:27:22 protocol basically uh uh that shows how efficient this protocol is but even here
01:27:28 you can see that like uh if you basically strip off this feature with
01:27:33 caching uh on the client then it's going to send something
01:27:39 like uh 50 sorry uh 1.5 million calls
01:27:45 per second and uh that's five times faster than HTTP client would do uh by
01:27:54 wearing the same service um well and this is the result you would get in like normal case in
01:28:03 sense that there is no Fusion no Fusion clim nothing so that's what you are
01:28:10 expected to have in in case you don't add any extras and by the way nearly the
01:28:15 same you would get nearly the same output if you would use r cach on top of
01:28:21 that I mean together with this thing I'll show you why uh quite soon or maybe
01:28:29 like maybe it's going to be in the next video
01:28:36 okay so uh let's see uh what's the output right for
01:28:44 our um Benchmark that we run in Docker so
01:28:49 it's a kind of quite close to what you just so so it's like slightly lower
01:28:57 numbers but still interestingly that https I mean the HTTP client like just
01:29:03 inside the docker is it's marginally faster
01:29:09 okay so let's let's stop this thing
01:29:16 um oh let me show you one more thing related to uh our samples right
01:29:24 um so is it running yeah it's running uh
01:29:30 let's run console client for this sample because it's it's kind of
01:29:36 interesting to see how it's going to work will it work so that's the
01:29:46 sample oh my God I I want to run it
01:29:55 let's stop console client uh I want to run it in uh
01:30:01 dedicated now I mean yeah external
01:30:10 conso mhm okay yeah
01:30:16 let's can we do something like this uh
01:30:22 yeah uh so since we are not authenticated I don't have to uh use any
01:30:28 session ID it's still going to use the same set of items I mean Global one remember so I'm just uh okay I have to
01:30:38 enter something I guess um basically there is some validation
01:30:45 Logic for this station ID think uh doesn't allow you to use short IDs so
01:30:55 um yeah these are our items right let's change
01:31:02 something yeah it changed let's delete
01:31:07 [Music] delete so it works uh so uh let me show you the client uh so as you might guess
01:31:16 it's very simple up right and um
01:31:26 uh yeah this [Music] one
01:31:31 okay um
01:31:39 so what do we have here so station ID let uh like Let's
01:31:46 ignore this stuff what we do here is we build service provider by adding Fusion
01:31:53 adding soet client add think authentication client to do API uh so this thing is used in like uh
01:32:02 RPC demo part we don't need it here actually and we can comment it out but
01:32:09 the point is like uh so how it gets these updates in real time right and
01:32:14 then it like at some point it calls observe to do and uh you see that like
01:32:22 what you can do is for example example you can create a new computed which is uh wrapping this
01:32:31 computation you instantly update this because like this thing I mean this part
01:32:36 can be executed synchronously and to compute something you need like uh to
01:32:42 run a synchronous computation this thing this thing all of this is a synchronous
01:32:47 right so we want B basically if uh we remove this part and the first value
01:32:53 it's going to be output it's going to be the default basically for like this
01:32:59 thing um and default uh for this for the type of
01:33:06 like what's this so basically now in this case right okay and uh then you can observe
01:33:17 changes like this there are lots of so these the overloads for changes methods
01:33:23 and some other uh you see that for example there is an update delayer you can pass uh let me show
01:33:31 you delayer get well so this is going to be one
01:33:38 second delay and let's also yeah oh did I click stop consol client
01:33:47 let's run it again so uh the first update is quick of
01:33:55 course because we run it explicitly but like let
01:34:00 me move it to so I click here one second
01:34:05 later you see the change here and like that's the power of this abstraction
01:34:11 basically it uh allows uh you to see things in inconsistent State and know
01:34:18 about this okay uh I guess we are done with this this
01:34:24 part um like what's the impact of all of this in real
01:34:30 apps and uh you can find this chart in Fusion repository I mean on fusion page
01:34:39 uh but basically it shows how uh our actual server responds to one of the
01:34:46 most frequent calls chat get tile it's basically returns like five messages uh
01:34:53 starting from from like certain uh boundary uh so you see that most of
01:35:00 these calls are resolved in 30 microsc it's not milliseconds it's
01:35:06 microsc and uh like we get timings like three milliseconds only when uh it
01:35:14 actually hits the database um moreover I think what kind
01:35:20 of what's important here is that like most of these calls are actually
01:35:27 eliminated on the clients so these are the calls that kind of made it to the
01:35:33 server uh and way more calls of course were eliminated on The Client because
01:35:39 the value was still the same uh okay yeah that's a famous quote on cash
01:35:47 in validation and unsurprisingly naming things uh so the interesting piece here
01:35:54 is I guess that like Fusion offers a fancy solution to this
01:36:01 problem now like how many calls are actually tracked in Fusion based apps so
01:36:11 actual chart is a good example here and as you can see like uh in for example in
01:36:18 my case it tracks I think uh more than 1,000 calls so basically these are the
01:36:25 values it kind of watches on the server side
01:36:30 observes um and it costs nothing like uh it
01:36:37 moreover uh now I'm going to also show yeah so that's like how the actual uh
01:36:45 cache looks like it uses index DB uh in case with actual chat not local storage
01:36:51 because like local storage is like there are much more constraints right but uh
01:36:57 you can see that uh so that's for def instance and that's why uh the number of
01:37:02 Kiss is much lower here but it's still 600 uh so basically 600 results of
01:37:09 calls are cached right and uh this is how actual Network
01:37:15 traffic looks like uh so you see that that's the very beginning of the communication and the protocol used here
01:37:21 is also a little bit kind of out dated I I think I made this screenshot maybe a
01:37:28 month ago or so and I made a bunch of improvements to the protocol so right now it's much more efficient but the
01:37:34 point is like you see that like after the handshake it sends again one big
01:37:41 call with like well sorry one big packet which kind of packs a bunch of calls
01:37:48 right and then like it starts getting uh so the first response is like almost 5
01:37:54 kilobytes it also uh includes the data for like a number of calls you can see I
01:38:01 think what's highlighted here is that like uh you even can see by the pattern
01:38:07 that probably it's uh the same method that uh sorry the same kind of response
01:38:16 and yeah that's match response telling that basically hey your value uh that's
01:38:22 catched is still correct so okay we are getting to the
01:38:29 very final part right now and
01:38:34 uh there is a bunch of kind of comparison slides uh for what Fusion
01:38:42 versus some more kind of well-known abstractions so for uh State Management
01:38:50 abstractions like fluxer MX and Redux and there are many of them uh I think
01:38:59 the key difference between fusion and them is that Fusion is distributed of
01:39:04 course then it's also threat safe and as synchronous and that's important because
01:39:10 uh this is what makes Fusion kind of a fit for server side piece so you don't
01:39:16 have to use it on the client you can use it just on the server side and uh this will speed up your basically API
01:39:26 um one other interesting thing is that like I think no one does the same stuff
01:39:31 with methods as what Fusion does basically this kind of decoration part
01:39:37 and impling cach implicit caching um yeah most of these
01:39:44 obstructions they are very explicit in terms of like expressing that you want
01:39:49 certain computation to be dependent on like like so there are no like methods
01:39:55 with you can just call right and um again it's quite important thing
01:40:02 because that's what makes your code clean and readable uh well as for
01:40:07 everything else I think uh uh yeah uh well I I'll probably skip it
01:40:14 for now but you can read right there are of course like many other
01:40:20 differences okay now so what people typically use to address
01:40:27 these real time scenarios right and I think one of most well-known kind of
01:40:33 combinations is signal R Plus radius um so uh why you may want to use
01:40:41 Fusion instead well because uh it's simple versus easy and I think I'll get
01:40:49 back to this part later and like uh we will touch this topic but the point
01:40:55 is like Fusion offers a
01:41:01 framework um something that like allows you to build uh
01:41:09 well everything in a consistent fashion like every piece of realtime logic is
01:41:16 going to look the same with fusion and as for signal and radius sorry signal R
01:41:22 and radius uh yeah you will be basically doing the same but like each time you are going to
01:41:28 solve the same problem again and again and in the end like of course this approach is way more error prone because
01:41:36 all depends on a developer who works on a given part of the app and if they know
01:41:42 how like uh to do it right then it's going to maybe work well but what if
01:41:49 they don't right and uh so yeah and finally it's kind of it's a lot
01:41:58 about reliability right so if the framework takes care of like uh making
01:42:06 certain things work the same way it's actually way better than like when a
01:42:14 developer a different developer uh each time takes care of the
01:42:20 same problem CU like okay it may be solved in 80% of cases but like the
01:42:26 remaining 20% are not going to work well and moreover these issues are extremely
01:42:32 hard to debat or like even identify uh so I think the picture here
01:42:38 is kind of shows that like yeah you can kind of drive on manual transmission but
01:42:44 like who does it nowadays um so and I think the
01:42:51 interesting scenario or like one interesting Cas is like graphql uh and
01:42:57 similar protocols because they sort of uh at least the perception is that they
01:43:04 can help you to solve the same problem and uh well the harsh truth is that not
01:43:14 quite if you think about what Fusion does is like in terms of efficiency and
01:43:20 so so on of course like graphql allows you to I'll basically reshape the results and filter out the stuff you
01:43:26 don't need but like each time you refresh the page each time you start a
01:43:31 client or like even like go to a certain part of UI maybe sometimes right you're
01:43:37 going to get this data from server as a single huge box and that's what's shown
01:43:43 on the right side right as for the fusion scenario you saw that like in
01:43:50 reality first of all it kind of doesn't need this thing with well basically
01:43:57 boxing everything into a single box it it does it like completely differently
01:44:04 it allows you to literally like uh run the computation in such a way that the
01:44:11 client uh well just uh sends request to
01:44:17 each individual single small item and nevertheless all these requests give at
01:44:23 once um and like literally in a single Network pocket and moreover the response
01:44:29 will be much shorter because more likely than not they are cashed on the client
01:44:34 so that's I think in case with actual chat for example the traffic you get on
01:44:40 reconnect is typically just 10 kilobytes it's like when it reconnects or restart you restart the app you get 10 kilobyte
01:44:47 of traffic uh for the sake of clarity I think in May I mean this year in May the
01:44:54 traffic was about 1 Megabyte and that's uh before the moment we added this
01:45:00 protocol that kind of uh I mean we added this extension for local caches and
01:45:07 stuff like this uh because and I think that's what you are kind of expected to
01:45:12 have with signal R sorry with graphql for example so yeah you you basically um
01:45:18 you may uh optimize things and so so on but like if if there is nothing like
01:45:25 this and the like there is no cash or if there is a cash that it's not like
01:45:32 tweaked for tiny items you fetch individually there is so like you
01:45:39 wouldn't get the same result and uh um yeah that's the
01:45:46 scenario okay so there are a few more uh
01:45:51 code examples from ual chat um and uh
01:45:56 I'm not going to like um I guess um cover them in all the details I I'll
01:46:03 just show that you can use all of this stuff so for example here uh this
01:46:12 um stuff with observing a result of some computation you see that online 81 for
01:46:19 example we call computer. new then create a computed which basically in the
01:46:25 end it returns a single Boolean right but like it basically awaits when you either uh leave the uh homepage or your
01:46:36 account changes and uh yeah you can like create a computer that computes this
01:46:41 value and await for it and uh basically create some logic that based on this so
01:46:47 you can observe literally the sequence of uh so you
01:46:53 let me rephrase this you can await that uh user uh on like of your up takes a
01:47:03 sequence of steps and hits certain State and uh the like you can do this uh
01:47:11 because every piece of your UI uh is like Fusion based so for example like
01:47:18 service that Returns the current user account right or the browser history service history is browser history
01:47:25 service that that that knows the like where you are in the app I mean in which
01:47:31 URL and like what steps you took um so basically if all of this is based on
01:47:36 Fusion then you can just wait for certain state to
01:47:42 happen and finally testing right so in tests you can use this construction
01:47:48 which calls a bunch of uh compute methods to again a wait when certain
01:47:54 assertion kind of passes through in this case it's like chat IDs should not
01:47:59 contain chat ID right so basically like the list of chat IDs that is produced
01:48:05 here it's like uh there is no more certain chat in your contacts here and
01:48:11 yeah this when is going to wait for up to 10 seconds and like recompute this thing every time something changes and
01:48:19 uh once uh well basically this thing doesn't an exception it exits more like
01:48:25 otherwise it will fail if it cannot satisfy it in certain time out so you
01:48:31 can use this stuff in tests oh and that's a very ancient
01:48:37 example I think it's like one of other like one other trick you can do in all
01:48:43 these compute methods it's like you basically get the current computed and automatically invalidated after a
01:48:50 certain period of time uh to make this thing recompute if
01:48:57 someone uh watches over it right if no one watches then uh well okay you
01:49:02 invalidated it but like who cares but if someone observes the value of this thing
01:49:08 or uses it in some other computer right then like uh uh they will see the change
01:49:15 every second okay so uh I guess
01:49:23 um the purpose of this talk was to kind of um give
01:49:30 you um an impression of what Fusion is about and what kind of problems it
01:49:37 solves and uh yeah there are probably more questions than answers but like
01:49:45 uh I think thinking about questions or like asking questions is I guess the first step to get his answers and that's
01:49:52 normal right uh
01:49:57 so why all of this is so important uh in my opinion because you can rarely get a
01:50:07 performance Simplicity and like low cost
01:50:12 I mean if we are talking about implementing some real time stuff then Fusion is like extremely lowc cost
01:50:19 solution I'll show you later like how how tiny is the amount of code
01:50:24 responsible to for real time in actual chart for example and um so um basically you get
01:50:34 like 100x performance uh nearly the same Simplicity as you used to have without
01:50:40 real time and like like the cost of real time is nearly zero for you
01:50:46 okay and yeah you saw these numbers already but that's the speed up you are
01:50:51 guante you kind of get right uh and that's a visualization of this speed up
01:50:59 I mean literally a single server May uh handle a lot that otherwise would be uh
01:51:07 handled by hundred of servers and that's it's crazy
01:51:15 right now like uh what are some other reasons or like what might be some other
01:51:21 reasons for you to try all of that well there was a famous I mean there is a
01:51:28 famous St overflow survey they run it every year and uh one of questions in
01:51:33 the last one was like what causes the most frustration for
01:51:40 developers um it's easy to predict the number one item right and it's the
01:51:47 amount of technical do in like literally every system that lives for like
01:51:55 years that's number one kind of downside
01:52:01 or like now number one thing that bothers everyone well at least like if
01:52:07 we're talking about developers right uh so
01:52:15 uh what else developers care about they want to improve the quality of code they
01:52:22 want want to learn you Tech and I'll skip a bunch of items and they want to contribute to open
01:52:28 source and uh like think what what basically kind of checkboxes
01:52:35 fusion uh crosses in this case and uh yeah speaking of simple
01:52:43 versus easy um I mentioned this earlier there is a
01:52:49 famous top which uh has exactly this name uh or like almost exactly this name
01:52:57 simple Made Easy uh the author of this talk is the
01:53:02 creator of closure and uh uh yeah it's all about
01:53:07 like why it's important to um reduce the complexity of your
01:53:15 system so the the chart shown here is uh
01:53:24 um shows the long-term impact of all these changes basically uh uh his
01:53:32 description of easy versus simple is nearly this easy is what's
01:53:39 easy to use easy to learn and uh like basically requires zero efforts to kind
01:53:46 of start to uh or like
01:53:52 B basically easy is something that doesn't require you to invest some time
01:53:59 to learn adopt and use and on contrary
01:54:04 simple is something that may require a decent investment in the beginning but
01:54:11 in the end it allows you to produce a code that everyone understands the
01:54:17 maintainable code that kind of code that's easy to read so uh
01:54:24 obviously yeah you can basically I think and it's also a lot about the level of
01:54:30 obstruction right so simple can be of a higher level of abstraction and that's
01:54:36 why it requires you to kind of invest into uh studying it or like using it but
01:54:45 like easy can be like easy so no investment uh but the problem
01:54:52 is that like basically if you use these like lowlevel abstraction things right
01:54:58 then you will quickly get into a state where you're like the system you build becomes kind of unmaintainable and hard
01:55:05 to evolve okay and uh I think this illustration is
01:55:12 uh a good example of like what level of abstraction means or like what I guess
01:55:18 simple versus easy means uh so if you don't know about Ayn weight then the Cod
01:55:25 on the left looks perfectly fine for you like you may even think like okay uh
01:55:33 probably there is no better way to do that right and uh on the other hand if
01:55:39 you know about a SN weight then this code looks kind of dumb
01:55:44 right so speaking of fusion that's what uh that's nearly what it does with
01:55:52 your code it's like yeah it's well probably even better because like it
01:55:57 like in reality your new code looks almost like what you would right
01:56:03 otherwise without any real time stuff catching them blah blah blah okay
01:56:10 uh so what's the cost of like using fusion and uh the cost of well basically
01:56:18 building real time up on top of f
01:56:24 uh so if you look uh at the bottom part of the screen
01:56:29 you will see that I was searching for if invalidation do is
01:56:35 right uh and basically I counted the number of invalidation blocks in actual
01:56:43 chat so the total number is 90 it's like 90
01:56:49 blocks uh and I think the total number of lines of quot is something like I
01:56:55 don't remember exactly but probably like 200,000 something like this um so it's a
01:57:02 a tiny tiny percent of cod like literally tiny percent of cod that makes
01:57:10 like probably like almost the whole real time so so at
01:57:16 least except maybe some rare Parts it's like what uh allows seual chat to
01:57:23 display changes in real time uh I think
01:57:29 uh I also remember that like uh I wrote a smaller sample but kind of close to
01:57:36 real life as well board games and the number of invalidation calls there was
01:57:41 around I think 30 or so to the invalidation blocks so basically like
01:57:46 the Delta between an up you can write in like a week or so and an up but you like
01:57:53 your team may uh spend like years on uh
01:57:59 it's like not that big so what are some other benefits of
01:58:07 uh Fusion well that's one of such benefits right
01:58:12 typically you can't have the same code for implementing uh Blazer server up and
01:58:20 Blazer web assembly up but not with fusion with Fusion it's exactly the same
01:58:26 code
01:58:31 uh I already mentioned that but the same is applicable to monolith versus
01:58:37 microservice scenario and uh again it's
01:58:42 the same thing uh if every service you build behaves nearly the same way
01:58:50 whether it's local or mod then like what stops you from turning a system that is
01:58:59 completely local like running on single server into a distributed one
01:59:05 nothing um so and yeah speaking of like many other evils you may face otherwise
01:59:14 there are plenty of them uh it's um well literally a pleora of tools that
01:59:24 may help you to uh Implement real time Behavior or caching or
01:59:30 whatever but uh the problem is that like you need to learn all of them like all
01:59:36 of them in most of cases and all of them have their own issues and so so on and
01:59:43 even if you think about like such simple scenario as UI for example right with
01:59:48 Fusion you don't need any extra on UI because like the abstraction works
01:59:54 everywhere on UI or like on like server site it's the same thing right and uh if
02:00:01 you don't use it then you need something like fluer or whatever and uh the same about I mean
02:00:08 the same is applicable to caching and same is applicable to some like uh
02:00:14 transmission protocol like signal ER and stuff like this and like you really need
02:00:19 to kind of learn all of that and and Tackle problems associated with any of
02:00:25 these uh tools so okay we are getting back to uh
02:00:33 the repository slides I guess which means that we are almost in the end of
02:00:39 this talk yeah that's the URL uh you need
