Is real-time UI
really hard to code
or do I suck?

You'll learn:

  • What do you need to have a good real-time UI?
  • How real-time is related to cache invalidation and eventual consistency?
  • What really makes React and Blazor so convenient?
  • How all of this is related to functional programming?
  • And many other things...

Typical Real-time UI Data Flow

Reads: UI ← Client ← API ← Services ← DB & other storages
Updates:

  • UI must subscribe to (and unsubscribe from!) domain events (error prone)
  • These events must be transformed to UI model changes (breaks DRY)
  • The UI displaying these models must be updated
  • Server-side code must implement event sourcing / CQRS
  • ... a lot more ...

But the main downside is:

Your UI becomes implicitly dependent on the server-side change processing logic. It accumulates more and more knowledge of which models & parts of the UI are impacted by which changes.

UI as a Composition of Functions

// Client
string RenderAppUI() {
  // Uses router, which ends up calling RenderUserName
}

string RenderUserName(string userId) {
  var user = UserApiClient.GetUser(userId);
  return $"<div>{user.Name}</div>";
}

// API controller
UserModel GetUser(string userId) {
  var user = UserRepository.Get(string userId);
  return new UserModel(user.Id, user.Name, ...);
}

// UserRepository
User Get(string userId) { ... }

Why don't we use this approach?

  1. It's quite expensive to recompute everything on every update
  2. And quite time consuming, because a part of these functions require RPC.

But wait...

  1. It's quite expensive to recompute everything on every update
    Cache use you must?
  2. And quite time consuming, because a part of these functions require RPC.
    Client-side cache use you must?

To Cache

means to store and reuse the results of computations executed in past.

Do we cache everything?

Caching as a Higher Order Function

Func<TIn, TOut> ToCaching<TIn, TOut>(Func<TIn, TOut> computer)
  => input => {
    var key = CreateKey(computer, input);

    if (TryGetCached(key, out var output)) return output;
    lock (GetLock(key)) { // Double-check locking
      if (TryGetCached(key, out var output)) return output;

      output = computer(input);
      StoreCached(key, output);

      return output;
    }
  }

var getUser = (Func<long, User>) (userId => UserRepository.Get(userId));
var cachingGetUser = ToCaching(getUser);

A Small Problem*

The code you saw works only when computer is a pure function.

So you just saw a tiny example of vaporware.

(*) Let's omit all minor issues for now – such as the fact it's non-async code.

Solutions*

Plan 😈: Purify every function!

Plan πŸ™€: Implement dependency tracking + cascading invalidation

(*) I'm absolutely sure there are other solutions. But there is no more space on this slide, so...

Plan πŸ™€: Caching + Dependency Tracking + Invalidation

Func<TIn, TOut> ToAwesome<TIn, TOut>(Func<TIn, TOut> computer)
  => input => {
    var key = CreateKey(computer, input);
    if (TryGetCached(key, out var computed) || Computed.IsInvalidating) // [ThreadStatic]
      return computed.UseOrInvalidate();
    lock (GetLock(key)) {
      if (TryGetCached(key, out var computed))
        return computed.Use();

      var oldCurrent = Computed.Current; // [ThreadStatic]
      Computed.Current = computed = new Computed(computer, input, key);
      try {
        computed.Value = computer(input);
      }
      catch (Exception error) {
        computed.Error = error;
      }
      finally {
        Computed.Current = oldCurrent;
      }

      StoreCached(key, computed);
      return computed.Use();
    }
  }

Computed.Use() = dependency tracking

static TOut Use<TIn, TOut>(this Computed<TIn, TOut> computed)
{
  Computed.Current.AddDependency(computed);
  return computed.Value;
}

static TOut UseOrInvalidate<TIn, TOut>(this Computed<TIn, TOut>? computed)
{
  if (Computed.IsInvalidating) { // [ThreadStatic]
    // Invalidation mode is on, so just invalidate & don't compute anything!
    computed?.Invalidate();
    return default;
  }
  return computed.Use();
}

What is invalidation / Computed.Invalidate()?

public void Invalidate()
{
  if (State == State.Invalidated) return;
  lock (this) { // Double-check locking
    if (State == State.Invalidated) return;
    State = State.Invalidated;
    RemoveCached(Key);
    InvalidateDependants(); // Calls Invalidate() on dependants
    OnInvalidated();
  }
}

Invalidation mode: call to invalidate the call result!

static void Computed.Invalidate(Action action)
{
  var oldIsInvalidating = Computed.IsInvalidating;
  Computed.IsInvalidating = true;
  try {
    action();
  }
  finally {
    Computed.IsInvalidating = oldIsInvalidating;
  }
}

Caching + Dependency Tracking Example

var counters = new Dictionary<string, int>();

// Dependency
var getCounter = ToAwesome((Func<string, int>) (key
  => counters.GetValueOrDefault(key)));

// Dependent function
var getCounterText = ToAwesome((Func<long, string>) (key
  => $"Count: {GetCounter(key)}"));

WriteLine(getCounterText("A")); // "Count: 0" - invokes both delegates
WriteLine(getCounterText("A")); // "Count: 0" - cache hit for getCounterText("A")

counters["A"] = 1;
Computed.Invalidate(() => getCounter("A")) // Invalidates both cached values
WriteLine(getCounterText("A")); // "Count: 1" - invokes both delegates again

Our new superpowers:

  • Call result caching
  • Dependency tracking
  • The same value is never computed concurrently

And it does this without changing neither the signature, nor the implementation of a function it gets!

"So, tell me, my little one-eyed one, on what poor, pitiful, defenseless planet has my monstrosity been unleashed?"
– Dr. Jumba Jookiba, #1 scientist in my list

The Incrementally-Build-EVERYTHING Decorator!

Let's remember where we started:

  1. It's quite expensive to recompute everything on every update
    Cache use you must?
    • But what if some of our functions are impure?
      Not a problem this is anymore!
  2. And quite time consuming, because a part of these functions require RPC.
    Client-side cache use you must?
    We'll get back to this part later.
A transparent furniture abstraction!*
(*) Except Computed.Invalidate – nothing is prefect :(

Do we really need this syntax with delegates?

We don't. It's actually much more convenient to apply this decorator to virtual methods tagged by a special attribute by generating a proxy type in runtime that overrides them.

What else is missing?

  • Actual implementation of a "box"
  • Async support
  • GC-friendly "box" cache
  • GC-friendly refs to dependants
  • A lot more. But slides are to show the bright side of things, right?

What about eventual consistency?

What about React and Blazor?

Flash Slothmore is eventually consistent:

He will close all of his tasks-in-slow-progress eventually.
Once Judy Hopps stops distracting him with her problems
(stops giving him more tasks).

– Bro, do you have a cache?
– I do - but it's so tiny...
– We are doomed! The state is eventually consistent!

Imagine two eventually consistent systems -
what's their key difference?

          #1

#2

I'm in the real-time business. How this is relevant?

Real-time updates require you to:

  • Know when a result of a function changes
    Invalidate all the things!
  • Recompute new results quickly
    Incrementally build all the things!
  • Send them over the network
    *.NET all the things?
  • Ideally, as a compact diff to the prev. state
    Diff can be computed in O(diffSize) for immutable types (details).

"There are only two hard things in Computer Science: cache invalidation and naming things."
– Phil Karlton


Naming problem is of the same scale as the Ultimate Question of Life, the Universe, and Everything, so... Good we've made a meaningful progress with a simpler one!

Blazor is:

  • .NET running in your browser
  • Nearly 100% compatibility with .NET 5!
    • Expression.Compile(...), Reflection, etc. works
    • No threads yet, but Task<T> works
  • Blazor UI Components ≃ React Components, but with .NET bells and whistles!

Blazor – cons:

  • No JIT / AOT compilation yet - in fact, everything is interpreted
  • It's .NET, so even a tiny project loads a fair number of assemblies.
    There is linking with tree shaking, but even it leaves 2…4 MB of .dlls.

Blazor – pros:

  • .NET = so many ready-to-use NuGet packages + no need for JS, TS, etc.
  • .dlls are loaded once & stored in application cache.
    They aren't updated even on F5 – unless you explicitly clear it.
  • Blazor Server helps to mitigate this by further letting your UI code to run on server side (e.g. for slow mobile devices). The JS payload is tiny in this case.
  • AOT and threads are expected in 2021.
    JS won't get threads - ever. CPU core count is increasing. So I bet in 1-2 years WASM (and Blazor) will be #1 choice for truly responsive UI.
  • There is experimental Blazor Mobile: like React Native, but relying on Blazor compontens and native .NET runtime on each platform.

Blazor Components - UI markup example

<div class="@CssClass" @attributes="@Attributes">
    <div class="card-body">
        <h5 class="card-title">
            <Icon CssClass="@IconCssClass" />
            @Title
        </h5>
        <div class="card-text">
            @ChildContent
        </div>
    </div>
</div>

Blazor Components - compiled version of above markup

protected override void BuildRenderTree(RenderTreeBuilder __builder)
{
  __builder.OpenElement(0, "div");
  __builder.AddAttribute(1, "class", this.CssClass);
  __builder.AddMultipleAttributes(2,
    RuntimeHelpers.TypeCheck</* ... */>(
        (IEnumerable<KeyValuePair<string, object>>) this.Attributes));
  // ...
  __builder.OpenComponent<Icon>(7);
  __builder.AddAttribute(8, "CssClass",
    RuntimeHelpers.TypeCheck<string>(this.IconCssClass));
  __builder.CloseComponent();
  // ...
  __builder.AddContent(14, this.ChildContent);
  __builder.CloseElement();
  __builder.CloseElement();
  __builder.CloseElement();
}

Blazor Components - the same markup, functional style

protected override HashSet<Component> RenderChildren()
{
  var div = Element(this, 0, "div") // parent, key, type
    .SetAttributes("class", CssClass)
    .SetAttributes(Attributes));
  var icon = Component<Icon>(div, 7) // parent, key
    .SetAttributes("CssClass", IconCssClass));
  // ...
  return new new HashSet<Component>() { div, icon, ... };
}

protected void Render()
{
  var newChildren = RenderChildren();
  foreach (var c in Children.ToHashSet().ExceptWith(newChildren))
      c.Dispose();
  foreach (var c in newChildren)
      c.TryRender();
}

Blazor and React - so what's common there?

  • Virtual DOM = the result cache for Component<T>(...) & Element(...) calls:
    • Π‘ache miss = build a component
    • Cache hit = reuse the exiting one, + maybe rebuild its own Virtual DOM
  • TryRender() calls Render() for every component that changed after its last Render() call.


All in all, React and Blazor = an incremental builder for your UI!

Just specialized to produce a diff to apply to the real DOM or UI controls.

w:300px

Does ToAwesome() really exist?

Fusion Service Example

public class CounterService
{
  private volatile int _count;

  [ComputeMethod]
  public virtual async Task<int> GetCountAsync()
    => _count;

  [ComputeMethod]
  public virtual async Task<string> GetCountTextAsync()
    => (await GetCountAsync()).ToString();

  public async Task IncrementCountAsync()
  {
    Interlocked.Increment(ref _count);
    Computed.Invalidate(() => GetCountAsync());
  }
}

Fusion's IComputed<T>:

Below is a simplified version of "a box" storing call result, its dependencies, dependants, etc.:

interface IComputed<T> {
  // Computing -> Consistent -> Invalidated
  ConsistencyState ConsistencyState { get; }
  T Value { get; }
  Exception Error { get; }

  event Action Invalidated; // Event, triggered just once on invalidation
  void Invalidate();
  Task<IComputed<T>> UpdateAsync();
}
DEMO

Can we replicate IComputed on a remote host?

public class ReplicaComputed<T> : IComputed<T>
{
    ConsistencyState ConsistencyState { get; }
    T Value { get; }
    Exception Error { get; }
    event Action Invalidated;

    public ReplicaComputed<T>(IComputed<T> source)
    {
        source.ThrowIfComputing();
        (Value, Error) = (source.Value, source.Error);
        ConsistencyState = source.ConsistencyState;
        source.Invalidated += () => Invalidate();
    }

    // ...
}

Do the same, but deliver the invalidation event via RPC.

Your Web API call:

β†’ How's my app doing?
← Still alive.

1 request = 1 response.

Fusion API call:

β†’ How's my app doing? +publish
← Still alive. +watch pub-666
← Be brave, pub-666 is... Invalidated.

1 request = 1 or 2 responses,
the 2nd one might come much later.

The invalidation notifications are delivered via Publisher-Replicator channel. Fusion uses WebSocket connection for such channels now, but more options to be available eventually.

ComposerService - an example service relying on remote replicas

See it live: https://fusion-samples.servicetitan.com/composition
Source code: ComposerService, LocalComposerService.

public virtual async Task<ComposedValue> GetComposedValueAsync(
    string parameter, Session session)
{
  // Fusion magic: all these seemingly RPC call complete instantly w/o
  // a real RPC while the result they produce is known to be consistent.
  var chatTail = await ChatService.GetChatTailAsync(1);
  var uptime = await TimeService.GetUptimeAsync(TimeSpan.FromSeconds(10));
  var sum = (double?) null;
  if (double.TryParse(parameter, out var value))
      sum = await SumService.SumAsync(new [] { value }, true);
  var lastChatMessage = chatTail.Messages.SingleOrDefault()?.Text ?? "(no messages)";
  var user = await AuthService.GetUserAsync(session);
  var activeUserCount = await ChatService.GetActiveUserCountAsync();
  return new ComposedValue(
    $"{parameter} - server", uptime, sum,
    lastChatMessage, user, activeUserCount);
}

A real Blazor component that updates in real-time:

@inherits LiveComponentBase<ActiveTranscriptions.Model>
@using System.Threading
@using ServiceTitan.Speech.Abstractions
@inject ITranscriber Transcriber

@{
    var state = State.LastValue; // We want to show the last correct model on error
    var error = State.Error;
}

<DataGrid TItem="Transcript"
          Data="@state.Transcripts"
          TotalItems="@state.Transcripts.Length"
          Sortable="false"
          ShowPager="false">
    <DataGridCommandColumn TItem="Transcript"/>
    <DataGridColumn TItem="Transcript" Field="@nameof(Transcript.Id)" Caption="#"/>
    <DataGridColumn TItem="Transcript" Field="@nameof(Transcript.StartTime)" Caption="Start Time"/>
    <DataGridColumn TItem="Transcript" Field="@nameof(Transcript.Duration)" Caption="Duration"/>
    <DataGridColumn TItem="Transcript" Field="@nameof(Transcript.Text)" Caption="Text" Width="75%" />
</DataGrid>

@code {
    public class Model
    {
        public Transcript[] Transcripts { get; set; } = Array.Empty<Transcript>();
    }

    protected override void ConfigureState(LiveState<Model>.Options options)
        // Update delays are configurable per-state / per-component
        => options.WithUpdateDelayer(o => o.Delay = TimeSpan.FromSeconds(1));

    protected override async Task<Model> ComputeStateAsync(CancellationToken cancellationToken)
    {
        var transcriptIds = await Transcriber.GetActiveTranscriptionIdsAsync(cancellationToken);
        var transcriptTasks = transcriptIds.Select(id => Transcriber.GetAsync(id, cancellationToken));
        var transcripts = await Task.WhenAll(transcriptTasks); // Get them all in parallel!
        return new Model() { Transcripts = transcripts };
    }
}

How efficient is Fusion caching?

The method we're repeatedly calling in our performance test:

public virtual async Task<User?> TryGetAsync(long userId)
{
  await Everything(); // LMK if you know what's the role of this call!
  await using var dbContext = DbContextFactory.CreateDbContext(); // Pooled
  var user = await dbContext.Users.FindAsync(new[] {(object) userId});
  return user;
}

How efficient is Fusion caching?

The Reader async task (the test runs 3 readers per core):

async Task<long> Reader(string name, int iterationCount)
{
    var rnd = new Random();
    var count = 0L;
    for (; iterationCount > 0; iterationCount--) {
        var userId = (long) rnd.Next(UserCount);
        var user = await users.TryGetAsync(userId);
        if (user!.Id == userId)
            count++;
        extraAction.Invoke(user!); // Optionally serializes the user
    }
    return count;
}

There is also a similar Mutator, but only one instance of it is running.

How efficient is Fusion caching?

Sqlite EF provider: 16,070x

With Stl.Fusion:
  Standard test:
    Speed:      35708.280 K Ops/sec
  Standard test + serialization:
    Speed:      12481.940 K Ops/sec

Without Stl.Fusion:
  Standard test:
    Speed:      2.222 K Ops/sec
  Standard test + serialization:
    Speed:      2.179 K Ops/sec

In-memory EF provider: 1,140x

With Stl.Fusion:
  Standard test:
    Speed:      30338.256 K Ops/sec
  Standard test + serialization:
    Speed:      11789.282 K Ops/sec

Without Stl.Fusion:
  Standard test:
    Speed:      26.553 K Ops/sec
  Standard test + serialization:
    Speed:      26.143 K Ops/sec

And that's just a plain caching, i.e. no any extra benefits from the "incremental build for everything" that Fusion adds!

Fusion's Caching Sample

A very similar code, but exposing the service via Web API. The results:

  • 20,000 β†’ 130,000 RPS = 6.5x throughput
    With server-side changes only, i.e. the same client.
  • 20,000 β†’ 20,000,000 RPS = 1000x throughput!
    If you switch to Fusion client (so-called "Replica Service")
RestEase Client -> ASP.NET Core -> EF Core Service:
  Reads: 20.46K operations/s

RestEase Client -> ASP.NET Core -> Fusion Proxy -> EF Core Service:
  Reads: 127.96K operations/s

Fusion's Replica Client:
  Reads: 20.29M operations/s

How 10x speed boost looks like?

What do you get with Fusion?

The feeling of flight:

  • Caching - with automatic dependency tracking and cascading invalidation
  • The same value is never computed concurrently
  • But: all [ComputeMethod]-s can run concurrently!

What do you get with Fusion?

The feeling of awesomeness of your clean code:

  • You describe the substance.
    "That's what I want to get"
  • Fusion allows you to express this substance in the clean form.
    By ensuring you get what you want as efficiently as possible.

Just imagine, Fusion's Replica Services resolve 99.9% of your RPC calls locally, but still produce the right answers. And to achieve that, they span the web of their invalidation chains across multiple servers. Awesome, right?

What do you get with Fusion?

The feeling of laziness: you get all of that with almost zero changes in code!


Just add water Computed.Invalidate(...).
– AY, Fusion's creator

What do you get with Fusion?

The feeling of ultimate super power (together with Blazor):

  • You can run Fusion services on the client too!
  • Moreover, Fusion includes LiveComponent - a base base type for your Blazor components that has everything you need for real-time updates!
  • So you don't need a Knockout or MobX alternative for Blazor. Just use Fusion - everywhere!

Moreover, if you use the same interfaces for your Fusion services and their client-side replicas, your UI code will run equally well on the server side too! This is what allows Fusions samples to support both Blazor WebAssembly and Blazor Server mode.

What's the cost?

  • Money: thanks to ServiceTitan, Fusion is free (MIT license)
  • CPU: free your CPUs! The torture of making them to run recurring computations again and again must be stopped!
  • RAM: is where the cost is really paid. Besides that, remember about GC pauses and other downsides of local caching. But the upside is so bright + Fusion actually supports external caching via "swapping" feature.
  • Learning curve: is relatively shallow in the beginning, but getting steeper once you start to dig deeper. Though Fusion is definitely not as complex as e.g. TPL with its ExecutionContext, ValueTask<T>, and other tricky parts.
  • Other risks: First lines of Fusion code were written 9 months ago. What "other risks" are you talking about?

What's the cost?

If you need a real-time UI, Fusion is probably the lesser of many evils you'll have to deal with otherwise. *



(*) Fusion creator's opinion, totally unbiased.

Why having real-time UI is important?

On a serious note: Real-Time is #1 Feature Your Next Web App Needs





Thank you!
